Aluminium strip bars

Author:Frank Time:2023-05-05

aluminium strip bars

We are leading importer, exporter and supplier of aluminium strip bars that are known for their excellent electrical conductivity properties & very good bending properties. These cater to the panels, switchgear, earthing & other electrical strips applications & related industries and are available in different sizes, thickness and widths as per the requirements of the clients.

Properties

Aluminium and Copper Specifications


Parameters Aluminium Copper
Relevant Standards IEC 60105
ISO 209-1,2
IEC 60028
Physical Properties
Chemical Composition
Specific Heat     gm.cal/℃
Density         gm/cm2
Melting Point    ℃


0.092
2.91
660

99% pure
0.220
8.89
1083
Mechanical Properties
Ultimate Tensile Strength      kgf/mm2
Ultimate Shearing Strength    kgf/mm2
Elastic Modulus             kgf/mm2
0.2% Tensile-proof Strength   kgf/mm2

20.5/25
15
6,700
16.5/22

22-26
16-19
12000
60-80% of tensile strength
Electrical Properties
Specific Resistance         ʋʊcm
Volume Conductivity       ʋʊmm2
Conductivity              % IACS
Co-efficient of expansion    mm/m/℃

3.133
31.9
57
2.3*10-5

1.7241
58
100
1.73*10-5

Applications:
Commonly used in the manufacture of furniture, windows, stair rails, and in pipe railing
Commonly used in architectural extrusions
6063 aluminum bar is used for extruded and formed parts that can combine support with decoration
It is used for trim, decorative screens and grates and ornamental frames and supports

Specifications:
Ultimate Tensile Strength, psi: 27,000
Yield Strength, psi: 21,000
Hardness: 60
Chromium: 0.1 max
Copper: 0.1 max
Iron: 0.35 max
Magnesium: 0.45 - 0.9
Manganese: 0.1 max
Remainder Each: 0.05 max
Remainder Total: 0.15 max
Silicon: 0.2 - 0.6
Titanium: 0.1 max
Zinc: 0.1 max

                                          Mechanical Properties of Aluminum Bus Conductor and Related Alloys
                            (The Aluminum Association ; ASTM B 236, B 241, and B 429; and Manufacturer’s Listings)



Product Alloy and Temper Thickness in
Ultimates
Tensile Strength (ksi)
At 20 (68。F)
Typical
Ultimate
Typical Yield Typical(a)
Elongation
(Percent - in 2 in.
Or 4 Dia)
Minimum
Ultimate
Minimum
Yield
Extruded rod, bar tube,
pipe and shapes
1350-H111 All 8.5 3.5     35.0
6101-T6 0.125-0.500 29.0 25.0 32.0 28.0 15.0
6101-T61 0.125-0.749
0.750-1.499
1.500-2.000
20.0
18.0
15.0
15.0
11.0
8.0

6101-T63
6101-H111
6101-T64
6101-T65
0.125-0.500
0.250-2.000
0.125-1.000
0.125-0.749
27.0
12.0
15.0
25.0
22.0
8.0
8.0
20.0
14.0 11.0
Extruded pipe(c) 6061-T6
6063-T6
Pipe size 1.0 &
over Pipe sizes,all
38.0
30.0

35.0
25.0
45.0
35.0
40.0
31.0
10.0 min
8.0 min
Rolled bar 1350-H12 0.125-1.000 12.0 8.0 14.0 12.0
Sawed-plate bar or sheet 1350-H112 0.125-0.499
0.500-1.000
1.001-3.000
11.0
10.0
9.0
6.0
4.0
3.5
    10.0min
16.0min
22.0min
Rolled sheet
(for shearing or forming)
1350
1350-H12
1350-H14
0.020-0.249 8.0
12.0
14.0
  12.0
14.0
16.0
4.0
12.0
14.0
20-30 min
4-9 min
3-6 min
1350-H16
1350-H18
0.020-0.125 16.0
18.0
  18.0 16.0 2-4 min
2-4 min
Cast Alloy for Bus 1350-F
1050
1 in. And up     8.5 3.5 35.0
Cast Alloy for Fittings A356.0-T61   37.0       5.0

Aluminium strip bars Specifications and Features :
Aluminum Grades
Structural Grade: 6061
Structural Grade: 5052
Electrical Grade: 1100
Electrical Grade: 1350
Electrical Grade: 6101
Electrical Grade: 6063
Aluminum strips Plating Options
Silver, Tin, Nickel


Aluminium strip bars Insulation Options :
Heat Shrink, Powder Coat
