Henan Signi Aluminum could provides 6 series of Rare earth contained high conductive aluminum busbar plate . It is awarded the title of "excellent supplier" by Schneider electric of France. The detailed specification of Rare earth contained high conductive aluminum busbar plate 59%IACS is as follows:
| Size list of rare earth contained high conductive aluminum busbar plate | ||
| item name | width/mm | weight/meter kg/m |
| 6*** rare earth contained high conductive aluminum busbar plate | 23.9 | 0.39 |
| 63.5 | 0.92 | |
| 76.2 | 1.29 | |
| 85.8 | 1.46 | |
| 101.6 | 1.73 | |
| 114.3 | 1.95 | |
| 127 | 2.17 | |
| 137.16 | 2.34 | |
| 152.4 | 2.61 | |
| 165.1 | 2.83 | |
| 177.8 | 3.05 | |
| 190.5 | 3.27 | |
| 203.2 | 3.49 | |
| Length (m) | 3m--6m | |
| Width(mm) | 3.0mm--10.0mm | |
| Remark | Besides the sizes above, we could make customized products for customer. | |
| Mechanical performance of 6*** rare earth contained high conductive aluminum busbar plate | |
| Conductivity | 57-59%IACS |
| Hardness | HRF 56-60 |
| Tensile strength | 172.4-185.50Mpa |
| Remark | We could make different mechanical performance according to customer needs. |
